Fire Rated Ceiling Air Valves
Tenmat’s Fire-Rated Ceiling Air Valves are a unique and cost-effective fire-rated solution where recessed ceiling air valves are to be installed in fire-rated floor/ceiling constructions.
You are here:
Fire Rated Ceiling Air Valves
Tenmat’s Fire-Rated Ceiling Air Valves are a unique and cost-effective fire-rated solution where recessed ceiling air valves are to be installed in fire-rated floor/ceiling constructions.
PASSIVE FIRE PROTECTION
Limit the risk of fire and heat spread
In a fire situation, the integral intumescent material rapidly expands to seal off the air valve to help maintain the fire resistance rating of the ceiling. This limits the risk of fire and heat spread throughout the building. The Fire Rated Ceiling Air Valves are available in all common sizes for both Extract and Supply.
PASSIVE FIRE PROTECTION
For a wide range of residential and multiple occupancy buildings
The Fire Rated Air Valve is installed as normal with air flow through the air valve unaffected. The product requires no maintenance after installation. The Fire Rated Air Valves are suitable for domestic homes, as well as apartments, hotels and other multiple occupancy buildings where fire ratings exist.
Fire Rated Ceiling Air Valves at a glance
- Extract and supply versions
- 60-minute fire rating in solid timber joist floor/ceiling constructions
- 30-minute fire rating in metal web joist and solid timber joist floor/ceiling Constructions
- No maintenance required
- Meets requirements of Approved Document B
- Simple to install
Test Approvals
Fire Test Approvals
Successfully Fire Tested to BS EN1365-2 on Full Scale Loaded Floors including:
Solid Timber Joist Floor for 60 minutes
Engineered I-Beam Joist Floor for 30 minutes
Metal Web Joist Floor for 30 minutes
