VFB Plus

Tenmat’s VFB Plus Ventilated Fire Barriers are ’open state’ cavity fire barriers for ventilated cavities of up to 450mm.

VFB Plus

Tenmat’s VFB Plus Ventilated Fire Barriers are ’open state’ cavity fire barriers for ventilated cavities of up to 450mm.

PASSIVE FIRE PROTECTION

Specially formulated for fire stopping

Each VFB Plus consists of a specially formulated fire-rated stone mineral wool section with an integral high expansion intumescent seal fixed to the leading edge. The VFB Plus then leaves a maximum 44mm air gap to allow for drainage and maintain ventilation in normal use. In a fire situation, the intumescent seal rapidly expands to seal off the air gap and prevent vertical fire from spreading within the external wall.

VENTILATED CAVITY FIRE BARRIERS

Easy installation

The VFB Plus are mechanically fixed horizontally within ventilated cavities behind the external wall substrate following the fire compartment line.

The VFB Plus are used horizontally and can be installed in conjunction with Tenmat NVFB Non-Ventilated Fire Barriers which provide vertical fire separation along fire compartment party wall lines.

VFB Plus at a glance

3rd Party Certification from IFC Certification
Typical fire ratings of a minimum 30 to 60 minutes integrity and insulation
CCPI Verified
Higher fire ratings available dependent on the application
Maintains a 44mm air gap

Availability

To suit from 50mm up to 450mm cavities

Test Approvals

Fire Test Approvals

The products hold 3rd Party Certification from IFC Certification in conjunction with a Field of Application Report from IFC Ltd following extensive fire testing following the principles of BS EN1363-1 and in accordance with ASFP TGD19 (Fire Resistance Test for ‘Open-State’ Cavity Barriers).

3rd Party Certificate No. IFCC1750

Field of Application Report PAR 22672 01
