Tenmat’s VFB 60/60 Fire Barrier is an ’open state’ or ventilated cavity fire barrier for ventilated cavities of up to 450mm.
PASSIVE FIRE PROTECTION
Specially formulated for fire stopping
Each VFB 60/60 consists of a specially formulated fire-rated stone mineral wool section with an integral high expansion intumescent seal fixed to the leading edge. VFB 60/60 then leaves a maximum 25mm air gap to allow for drainage and maintain ventilation in normal use. In a fire situation, the intumescent seal rapidly expands to seal off the air gap and prevent vertical fire from spreading within the external wall.
PASSIVE FIRE PROTECTION
Fire resistance performance for cavities
The products hold 3rd Party Certification after having undergone extensive fire testing following the principles of BS EN1363-1 and in accordance with ASFP TGD19 (Fire Resistance Test for ‘Open-State’ Cavity Barriers). The VFB 60/60s are mechanically fixed horizontally within ventilated cavities behind the external wall substrate following the fire compartment line.
The VFB 60/60 ventilated cavity fire barriers are used horizontally and can be installed in conjunction with Tenmat NVFB Non-Ventilated Fire Barriers which provide vertical fire separation along fire compartment party wall lines.
VFB 60/60 at a glance
- 3rd Party Certification from IFC Certification
- Higher fire ratings available dependent on the application
- CCPI Verified
- Typical fire ratings of a minimum of 60 minutes of integrity and insulation
- Fixing brackets included as standard
- Maintains a 25mm air gap
- Up to 450mm cavities tested
- The standard thickness of 75mm
- Durability and age tested
Availability
Thickness (Total Cavity less 25mm Air Gap) x 75mm x 1000mm
- 60 Mins Integrity Fire Rating
- 60 Mins Insulation Fire Rating
- Maintains 25mm air gap
- Up to 300mm cavities
- Weather Proof/Age Tested
Test Approvals
Fire Test Approvals
The products hold 3rd Party Certification from IFC Certification in conjunction with a Field of Application Report from IFC Ltd following extensive fire testing following the principles of BS EN1363-1 and in accordance with ASFP TGD19 (Fire Resistance Test for ‘Open-State’ Cavity Barriers).
3rd Party Certificate No. IFCC1752
Field of Application Report PAR 22672 03
