OverSleeves

The Tenmat Fire Resistant Pipe Oversleeve is a universal, one-product-fits-all solution for the fire-stopping of combustible and insulated metal pipes.

OverSleeves

The Tenmat Fire Resistant Pipe Oversleeve is a universal, one-product-fits-all solution for the fire-stopping of combustible and insulated metal pipes.

MECHANICAL SERVICE PENETRATIONS

Fire-tested for fire-stopping performance

The thin and flexible intumescent is quickly and simply wrapped directly around combustible pipes or directly on top of pipe insulation without the need to cut back the insulation, ensuring that thermal and vapour seal performance is maintained.

The red branded foil can be easily checked and identified on-site to confirm that fire-stopping is in  place. The unique FF107 intumescent material rapidly expands to seal off combustible pipes or the insulation around non-combustible pipes to provide up to EI240 minutes fire rating.

FBC™ System Compatible indicates that this product has been tested, and is monitored on an ongoing basis, to assure its chemical compatibility with FlowGuard Gold®, BlazeMaster® and Corzan® piping systems and products made with TempRite® Technology.” “The FBC System Compatible Logo, FBC™, FlowGuard Gold®, BlazeMaster®, Corzan®, and TempRite® are trademarks of Lubrizol Advanced Materials, Inc. or its affiliates.

fbc-system-compatible

OverSleeves at a glance

Availability

  • 3mm x 180mm x 1000mm – 5-metre lengths per pack
  • 3mm x 280mm x 1000mm – 5-metre lengths per pack
  • Other sizes are available upon request, contact us for more information.

Approved Applications

  • Combustible pipes up to 160mm
  • Pipe materials including PVC-U, PVC-C,
  • HDPE, ABS, PP
  • Non-combustible pipes from 15mm to 219mm
  • Copper, steel and cast iron insulated pipes
  • Phenolic foam or glass mineral wool pipe insulation
  • Insulation thickness ranges from 15 mm – 50 mm
  • Suitable for drywall/plasterboard partitions, ablative coated fire batts, solid walls and concrete floors
  • Lubrizol approved
  • FBC system compatible

Test Approvals

UKCA Marked – Certificate: 0843-CPR-1350
UKTA Technical Approval: 0843-UKTA-23/0001

ETA Approval: ETA 23/0484

Declaration of Performance (DoP): Document No. QA028


FBC™ System Compatible indicates that this product has been tested, and is monitored on an ongoing basis, to assure its chemical compatibility with FlowGuard Gold®, BlazeMaster® and Corzan® piping systems and products made with TempRite® Technology.” “The FBC System Compatible Logo, FBC™, FlowGuard Gold®, BlazeMaster®, Corzan®, and TempRite® are trademarks of Lubrizol Advanced Materials, Inc. or its affiliates.

Resources

Contents

The Tenmat OverSleeve is a universal, one-product-fits-all solution for the firestopping of combustible and insulated metal pipes.
