FF109
Tenmat Firefly 109 is a compressible intumescent material which expands to form a resilient and stable char. The material is available in sheets of minimum 10 mm thickness or alternatively in formed shapes.
You are here:
FF109
Tenmat Firefly 109 is a compressible intumescent material which expands to form a resilient and stable char. The material is available in sheets of minimum 10 mm thickness or alternatively in formed shapes.
FIREFLY 109
Lower density and low expansion characteristics
Tenmat Firefly 109 is a lower-density material with lower expansion characteristics; this allows the material to function in a controlled manner without the need for additional restraints. Applications include pipe, socket, vent duct, or downlight penetration seals.
Firefly 109 at a glance
- 5:1 expansion ratio
-
Can be
vacuum-formed
- Resilient char formation
- Compressible
Applications
Socket box Inserts
Pipe Fire Sleeves
Downlight Fire Hood
Availability
See the Product Dimensions section below.
Product Dimensions
Tenmat Firefly 109 is available in a variety of standard sizes. It can be supplied in 610 x 1000 mm sheets with 10-60 mm thickness, or alternatively can be cut into strips of a defined length and width, within the sheet dimensions, or vacuum formed into various shapes. Tenmat offers all these options and sizes as standard to suit customer requirements
